F9.9 / F15 tot 2007
| Nummer | Bestelnummer | Yamaha OEM: | Omschrijving |
| 0 | REC6AH-W0078-00 | 6AH-W0078-00-00 | Waterpomp service kit |
|
0 |
REC66M-W0001-20 |
66M-W0001-20-00 |
Gearcase seal kit |
|
1 |
PAF15-06100000L |
66M-45300-11-4D |
Lower unit L |
| 2 | PAF15-06100000S | 66M-45300-02-4D | Lower unit S |
| 3 | REC93315-314V8 | 93315-314V8 | Bearing |
| 4 | PAF15-06000006 | 63V-45536-00 | Sleeve drive |
| 5 | REC93341-41414 | 93341-41414 | Bearing |
| 6 | PAF15-06000008 | 6E8-45587-10-13 | Shim |
| 7 | REC93332-00005 | 93332-00005 | Bearing |
| 8 | PAF15-06000010-1 | 664-45567-01-10 | Shim |
| 9 | PAF4-03000023 | 90340-08002 | Plug |
| 10 | REC90430-08020 | 90430-08020 | Gasket |
| 11 | REC63V-44301-00 | 63V-44301-00 | Pump housing |
| 12 | REC63V-44322-00 | 63V-44322-00 | Insert |
| 13 | PAF15-06060004 | 647-44366-00 | Damper |
| 14 | REC63V-44352-01 | 63V-44352-01 | Impeller |
| 15 | REC664-44338-00 | 664-44338-00 | Key |
| 16 | REC93210-44398 | 93210-44398 | O ring |
| 17 | REC63V-44323-00 | 63V-44323-00 | Outer plate |
| 18 | PAF15-00000013 | 93604-12M07 | Cover lower casing |
| 19 | REC97080-08045 | 97080-08045 | Bolt |
| 20 | PAF15-06000014 | 63V-44328-00 | Plate |
| 21 | PAF15-06020001 | 63V-45331-00-5B | Housing bearing |
| 22 | REC626-45316-09 | 626-45316-09 | Bushing |
| 23 | REC93101-20048 | 93101-20048 | Oil seal |
| 24 | REC63V-45315-A0 | 63V-45315-A0 | Gasket |
| 25 | REC93210-06ME6 | 93210-06ME6 | O ring |
| 26 | PAGB/T5783-M8X25 | 97080-08025 | Bolt |
| 27 | PAF15-06030000S | 63V-44150-00 | Shift cam S |
| 27 | PAF15-06030000 | 63V-44150-10 | Shift cam |
| 28 | REC63V-45501-11 | 63V-45510-11 | Drive shaft L |
| 28 | PAF15-06040000S | 63V-45510-00 | Drive shaft S |
| 29 | REC63V-45551-00 | 63V-45551-00 | Pinion |
| 30 | REC90179-08M06 | 90179-08M06 | Nut |
| 31 | REC6E7-45560-01 | 6E7-45560-01 | Gear |
| 32 | REC6E7-45570-00 | 6E7-45571-00 | Gear |
| 33 | PAF15-06080006-1 | 626-45577-00-01 | Shim |
| 34 | REC90201-17682 | 90201-17682 | Washer |
| 35 | REC683-45611-00 | 683-45611-00 | Shaft propeller |
| 36 | REC650-45635-00 | 650-45635-00 | Plunger |
| 37 | REC682-45631-00 | 682-45631-00 | Clutch dog |
| 38 | REC90250-05010 | 90250-05010 | Pin |
| 39 | REC648-45633-00 | 648-45633-00 | Spring cross pin |
| 40 | PAF15-06070002 | 90501-14M06 | Spring compression |
| 41 | REC683-45361-01-94 | 683-45361-02-4D | Cap lower casing |
| 42 | REC93306-00501 | 93306-00501 | Bearing |
| 43 | REC93315-317U2 | 93315-317U2 | Bearing |
| 44 | REC93101-17054 | 93101-17054 | Oil seal |
| 45 | REC93210-57M09 | 93210-57M09 | O ring |
| 46 | PAF15-06080003 | 93210-56M80 | O ring |
| 47 | PAGB/T5783-M6X20 | 97095-06020 | Bolt |
| 48 | PAGB/T97.1-6 | 92995-06600 | Washer |
| 49 | CM61N-45251-01 | 61N-45251-01 | Anode |
| 50 | REC66M-45371-00 | 66M-45371-00 | Tab trim |
| 51 | REC6E7-45987-00 | 6E7-45978-01 | Spacer |
| 52 | REC90171-10M01 | 90171-10M01 | Nut castle |
| 53 | REC91490-30020 | 91490-30020 | Pin cotter |
| 54 | PAF15-06020005 | 63V-45375-00 | Seal Rubber |
| 55 | PAF15-02000005S | 66M-44361-00 | Water tube small |
| 55 | PAF15-02000005 | 66M-44361-10 | Water tube large |
| 56 | PAF15-02000006 | 63V-44365-10 | Rubber water tube |
| SOL3111-093-08 | 683-45943-00-EL | Propeller |
-
