F20 / F25
| Nummer: |
Bestelnummer: |
Yamaha OEM: |
Omschrijving: |
| 1 |
PAGB/T3452.1-92 |
93210-26130 |
O ring |
| 2 |
PAF25-04000017 |
61N-44362-10 |
Tube water |
| 2 |
PAF25-04000017S |
61N-44362-00 |
Tube water small |
| 3 |
PAF25-04000016 |
65W-44328-00 |
Fixed plate waterpump |
| 4 |
PAGB/T5782-2000 |
|
Bolt |
| 5 |
PAGB/T97.1-85 |
|
Washer |
| 6 |
PAF25-04050004 |
6L2-44367-00 |
Damper water pipe |
| 7 |
PAF25-04050001 |
61N-44311-01 |
Shell water pump |
| 8 |
PAF25-04050002 |
61N-44322-01 |
Shell inner |
| 9 |
PAF25-04050003 |
93210-45161 |
O ring |
| 10 |
PAF25-04050000 |
|
Shell assy water pump |
| 11 |
PAF25-04040000 |
6H4-44352-02 |
Impeller assy |
| 12 |
PAF25-04000014 |
61N-44323-00 |
Outer plate |
| 13 |
PAGB/T5783-2000 |
|
Bolt |
| 14 |
PAGB/T97.1-85 |
|
Washer |
| 15 |
PAF25-04000012 |
65W-44176-00 |
Plate oring |
| 16 |
PAF15-06020004 |
93210-06ME6 |
O ring |
| 17 |
PAF25-04000013 |
61N-45127-00 |
Water seal |
| 18 |
PAF25-04000007 |
93604-10M03 |
Pin dowel |
| 19 |
PAF25-04000008 |
65W-45331-00-5B |
Base drive shaft |
| 20 |
PAF25-04000009 |
61N-45315-00 |
Seal |
| 21 |
PAF25-04010003 |
93101-22067 |
Oil seal drive shaft |
| 22 |
PAF25-04010000 |
61N-45510-10 |
Drive shaft assy |
| 22 |
PAF25-04010000S |
61N-45510-00 |
Drive shaft assy small |
| 23 |
PAF25-04000015 |
90280-03024 |
Semicicular key |
| 24 |
PAHI-CAP32004JRKOYO |
93332-000W5 |
Housing bearing |
| 25 |
PAF25-04000003-1 |
61N-45587-00-07 |
Shim t:0.7mm |
| 25 |
PAF25-04000003-2 |
61N-45587-00-10 |
Shim t:1.0mm |
| 25 |
PAF25-04000003-3 |
61N-45587-00-11 |
Shim t:1.1mm |
| 25 |
PAF25-04000003-4 |
61N-45587-00-12 |
Shim t:1.2mm |
| 25 |
PAF25-04000003-5 |
61N-45587-00-13 |
Shim t:1.3mm |
| 25 |
PAF25-04000003-6 |
61N-45587-00-14 |
Shim t:1.4mm |
| 25 |
PAF25-04000003-7 |
61N-45587-00-15 |
Shim t:1.5mm |
| 25 |
PAF25-04000003-8 |
61N-45587-00-16 |
Shim t:1.6mm |
| 26 |
PAF25-04000002 |
61N-45536-00 |
Bushing nylon |
| 27 |
PAF25-04030000L |
65W-44150-10 |
Cam assy shift rod |
| 27 |
PAF25-04030000S |
65W-44150-00 |
Cam assy shift rod small |
| 28 |
PAF4-03000023 |
90340-08M04 |
Plug hole oil |
| 29 |
PAF4-03000024 |
93210-06ME6 |
Gasket |
| 30 |
PAGB/T889.1-2000 |
|
Nut locking |
| 31 |
PAF25-04000023 |
6L2-45215-00 |
Water inlet B |
| 32 |
PAF25-04000031 |
688-45341-00 |
Plug drain |
| 33 |
PAF25-04000001 |
61N-45311-02-4D |
Lower casing |
| 34 |
PAGB/T5782-M6X125 |
|
Bolt |
| 35 |
PAGB/T861.1-87 |
92990-06300 |
Washer locking |
| 36 |
PAF15-06000004 |
61N-45251-00 |
Anode lower |
| 37 |
PAGB/T5783-2000 |
|
Bolt |
| 38 |
PAF25-04000021 |
61N-45214-00 |
Tab course |
| 39 |
PAGB/T820-M5X30 |
|
Screw pan head |
| 40 |
PAF25-04000022 |
6L2-45214-00 |
Water inlet A |
| 41 |
PAF25-04000006 |
90179-10M14 |
Nut pinion |
| 42 |
PAF25-04000005 |
61N-45551-00 |
Pinion |
| 43 |
PAF25-04000004-1 |
6L2-45567-10 |
Shim t:1.0mm |
| 43 |
PAF25-04000004-2 |
6L2-45567-11 |
Shim t:1.1mm |
| 43 |
PAF25-04000004-3 |
6L2-45567-12 |
Shim t:1.2mm |
| 43 |
PAF25-04000004-4 |
6L2-45567-13 |
Shim t:1.3mm |
| 43 |
PAF25-04000004-5 |
6L2-45567-14 |
Shim t:1.4mm |
| 44 |
PANTN4T-302051L |
93332-00005 |
Taper roller bearing |
| 45 |
PAF25-04020000 |
61N-45560-00 |
Gear forward |
| 46 |
PAF25-04060003 |
664-45631-02 |
Clutch dog |
| 47 |
PAF15-06070004 |
90250-05010 |
Pin clutch |
| 48 |
PAF15-06070005 |
648-45633-00 |
Ring clutch |
| 49 |
PAF25-04060006 |
648-45635-00 |
Plunger shaft |
| 50 |
PAF25-04060002 |
90501-10065 |
Spring clutch |
| 51 |
PAF25-04060001 |
612-45611-00 |
Shaft propeller |
| 52 |
PAF25-04060007 |
90201-20417 |
Plate reverse gear |
| 53 |
PAF25-04060000 |
|
Propeller shaft assy |
| 54 |
PAF25-04070004 |
61N-45571-00 |
Gear reverse |
| 55 |
PAF25-04070005-1 |
6L2-45577-00-10 |
Shim t:1.0mm |
| 55 |
PAF25-04070005-2 |
6L2-45577-00-11 |
Shim t:1.1mm |
| 55 |
PAF25-04070005-3 |
6L2-45577-00-12 |
Shim t:1.2mm |
| 55 |
PAF25-04070005-4 |
6L2-45577-00-13 |
Shim t:1.3mm |
| 56 |
PAF25-04070002 |
93210-64ME7 |
O ring |
| 57 |
REC93306-00612 |
93306-00612 |
Ball bearing |
| 58 |
PAF25-04070001 |
61N-45361-01-4D |
Cover lower casing |
| 59 |
PANTN HK2016HU |
93315-22004 |
Roller gearing |
| 60 |
PAF25-04070006 |
93101-20M07 |
Oil seal |
| 61 |
PAF25-04070003 |
93210-65M50 |
O ring |
| 62 |
PAGB/T5783-2000 |
|
Bolt |
| 63 |
PAF25-04070000 |
|
Cover assy lower casing |
| 64 |
PAF2020 |
93315-220V7 |
Needle bearing |
| 65 |
PAF25-04090000L |
65W-45300-10-4D |
Complete gear housing large |
| 65 |
PAF25-04090000S |
65W-45300-00-4D |
Complete gear housing small |
| 66 |
PAF15-00000006 |
93606-11M24 |
Pin dowel |
| 67 |
PAF25-02000019 |
90202-12060 |
Washer nylon |
| 68 |
PAF25-02000004L |
65W-44361-10 |
Tube water large |
| 68 |
PAF25-02000004S |
65W-44361-00 |
Tube water small |
| 69 |
PAF25-02000005 |
90430-12072 |
Gasket water pipe |
| 70 |
PAGB/T97.1-85 |
92995-10600 |
Washer |
| 71 |
PAF25-00000011 |
90105-10M12 |
Bolt |
| 72 |
PAF25-04000024 |
6L2-45987-01 |
Spacer propeller |
| 73 |
PAF25-04080000 |
664-45947-01-EL |
Propeller assy |
| 74 |
PAF25-04000025 |
689-45997-00 |
Spacer |
| 75 |
PAGB/T97.1-85 |
92990-14200 |
Washer |
| 76 |
PAF25-04000027 |
90171-14013 |
Nut |
| 77 |
PAGB/T91-1.6X12 |
91490-30022 |
Pin cotter |
