Bracket 1
| Nummer: | Bestelnummer: | Omschrijving: |
| 2 | PAF15-01010003 | PLATE |
| 3 | PAF15-01010001 | BOLT, CLAMP BRACKET |
| 4 | PAGB/T818-M6X8 | SCREW M6X8 |
| 5 | PAGB/T896-5 | CIRCLIP 5 |
| 6 | PAF20-01010301L | BRACKET, ROTARY (L) |
| 6 | PAF20-01010301S | BRACKET, ROTARY (S) |
| 7 | PAF15-01010311 | BUSH, NYLON |
| 8 | PAF15-01010302 | BUSH, ROTARY BRACKET |
| 9 | PAF15-01010002 | WASHER, NYLON |
| 10 | PAF15-01010100 | LEFT BRACKET ASSEMBLY |
| 11 | PAF15-01010200 | RIGHT BRACKET ASSEMBLY |
| 12 | PAF15-01010102 | SCREW, CLAMP |
| 13 | PAF4-01010004 | HANDLE |
| 14 | PAF4-01010005 | RIVET, CLAMP HANDLE |
| 15 | PAF4-01010003 | CLAMP PLATE |
| 16 | PAGB/T6170-M6 | NUT M6 |
| 17 | PAGB/T97.1-6 | WASHER 6 |
| 18 | PAF15-01010202 | TIGHTWIRE , EARTHING |
| 19 | PAGB/T5783-M8X12 | BOLT M8X12 |
| 20 | PAF15-01010306 | LEVER, ANGLE ORIENTATION |
| 21 | PAF15-01010316 | LONG SHAFT, LOCK ANGLE |
| 22 | PAJB/T9740.1-M6 | OILER M6 |
| 23 | PAGB/T5782-M6X145 | BOLT M6X145 |
| 24 | PAF15-01010305 | TILT CLAMP HANDLE ASSEMBLY |
| 25 | PAF15-01010313A | SUPPORT ASSEMBLY |
| 26 | PAF15-01010308 | BUSH |
| 27 | PAF15-01010309 | WASHER, NYLON |
| 28 | PAF15-01010312A | SHAFT, SUPPORT |
| 29 | PAGB/T818-M5X6 | SCREW M5X6 |
| 30 | PAF15-01010307A | LINK ROD |
| 31 | PAF15-01010304 | SPRING |
| 32 | PAF15-01010006 | BUSH |
| 33 | PAF15-01010317-3 | SHORT SHAFT, LOCK ANGLE |
| 34 | PAF15-01010317-2 | BRACKET, LOCK ANGLE |
| 35 | PAF15-01010317-1 | INNER BRACKET |
| 36 | PAF15-01010315 | SPRING, TORSION |
| 37 | PAGB/T896-4 | CIRCLIP 4 |
| 38 | PAF15-01010314A | SPRING, TENSION |
| 39 | PAF15-01010400 | LIMITATIVE ROD ASSEMBLY |
-
